主要特性和功能
- 出色的分析功能：高達 80 MHz 分析帶寬、+/-0.19 dB 幅度精度、-155 dBm DANL、10 kHz 偏置時 -118 dBc/Hz 相位噪聲和 81 dB W-CDMA ACLR 動態范圍
- 16 個測量專用軟件等豐富的功能滿足特定的應用需求，一鍵式測量功能可以簡化測量設置
-
Digital Demodulation Measurements E4443A-204 1xEV-DO 測量專用軟件，固定許可證 E4443A-BAF W-CDMA 測量專用軟件，固定許可證 E4443A-202 GSM/EDGE 測量專用軟件，固定許可證 E4443A-B78 cdma2000® 測量專用軟件，固定許可證 E4443A-BAC cdmaOne 測量專用軟件，固定許可證 E4443A-BAE NADC/PDC 測量專用軟件，固定許可證 E4443A-210 HSDPA/HSUPA measurement personality, fixed perpetual license E4443A-214 1XEV-DV measurement personality, fixed perpetual license E4443A-241 靈活的數字調制分析，固定許可證 E4443A-217 WLAN 測量專用軟件，固定許可證 E4443A-212 TD-SCDMA modulation analysis measurement personality, fixed perpetual license E4443A-213 HSPA/8PSK for TD-SCDMA modulation analysis measurement personality, fixed perpetual license Digital Demodulation Hardware E4443A-B7J Digital demodulation hardware Software E4443A-226 相位噪聲測量專用軟件，固定許可證 E4443A-219 噪聲系數測量專用軟件，固定許可證 E4443A-HB6 Prevention of unauthorized firmware upgrade E4443A-211 TD-SCDMA power measurement personality, fixed perpetual license E4443A-266 8566/8568 編程代碼兼容性套件 E4443A-233 Measuring receiver measurement personality, fixed perpetual license E4443A-215 外部信號源控制測量專用軟件，固定許可證 E4443A-HGT Allows Gate width of less than 10 uSec. E4443A-235 Wide BW digitizer external calibration wizard, fixed perpetual license E4443A-HS1 Increased level of security - write protects user files E4443A-239 EMC measurement personality, fixed perpetual license Inputs and Outputs E4443A-H70 70 MHz output E4443A-HB2 21.4 MHz output E4443A-H20 20 MHz if output at rear panel E4443A-HN9 Wideband IF out E4443A-H7L Aux log video out E4443A-123 可切換的微波預選器旁路 E4443A-124 Y 軸視頻輸出 E4443A-HY7 Improve gain 70 MHz output E4443A-117 安全擦除存儲器 E4443A-115 512 MB user memory E4443A-111 USB device side I/O interface E4443A-107 Audio input 100 kOhm Amplifiers E4443A-1DS RF internal preamplifier E4443A-110 內置射頻/微波前置放大器 Calibration Documentation E4443A-UK6 包含測試數據的商業校準證書 E4443A-A6J ANSI Z540-1-1994 校準 E4443A-AMG 校準 + 不確定度 + 保護頻段（認證） Wideband IF E4443A-122 帶寬數字化儀，80 MHz E4443A-140 帶寬數字化儀，40 MHz E4443A-23B CCITT filter for audio measurements, fixed perpetual license E4443A-HV5 Y-AXIS VIDEO OUTPUT modified to 856x output level Connectivity software E4443A-230 Benchlink web remote control software Accessories E4443A-1CP Rack mount kit with handles E4443A-1CM Rackmount Kit E4443A-1CN Handle kit E4443A-1CR Rack slide kit E4443A-015 6 GHz return-loss Measurement Accessory Kit Documentation E4443A-AB2 China - Chinese localization E4443A-ABD Germany - German localization E4443A-ABF France - French localization E4443A-ABJ Japan - Japanese localization E4443A-ABZ Manual set - Italian localization E4443A-AB1 Manual set - Korean localization Additional Documentation E4443A-0B1 Extra Manual Set MATLAB Bundle N6171A MATLAB 軟件
| 分析帶寬 | 80 MHz |
|---|---|
| 帶寬選件 | 標配 10，40、80 MHz |
| 1 GHz 時的 DANL | -169 dBm |
| 1 GHz 時，10 kHz 頻偏處的相位噪聲 | -118 dBc/Hz |
| 1 GHz 時，1 MHz 頻偏處的相位噪聲 | -147 dBc/Hz |
| 總體幅度精度 | ± 0.19 dB |
| 三階截獲（TOI），1 GHz 時 | +19 dBm |
| 1 GHz 時的三階動態范圍 | 116 dB |
| 應用——通用 |
|
| 性能水平 | ◆◆◆◆◇◇ |
| 標準衰減器衰減范圍 | 70 dB |
| 標準衰減器步進 | 2 dB |
| 可用應用 | 是 |
